| Displacement |
50Hz: 9.7 m3h-1 / 5.7 ft 3min-1 60 Hz: 1.7 m3h-1 / 6.9ft3min-1 |
| Speed (Pneurop 6602) |
50Hz: 8.5 m3h-1 / 5 ft 3min-1 60Hz: 10 m3h-1 / 5.9 ft 3min-1 |
| Ultimate pressure |
2 x 10-3 mbar / 1.5 x 10-3 Torr |
| Ultimate pressure GB I |
3 x 10-2 mbar / 2.3 x 10-2 Torr |
| Ultimate pressure GB II |
6 x 10-2 mbar / 4.6 x 10-2 Torr |
| Ultimate pressure with Fomblin® |
2 x 10-2 mbar / 1.5 x 10-2 Torr |
| Max inlet pressure for water vapour |
38 mbar / 28.5 Torr |
| Max water vapour pumping rate – GB I |
60 gh-1 |
| Max water vapour pumping rate – GB II |
220 gh-1 |
| Max allowed outlet pressure |
0.2 bar gauge / 2.8 psig |
| Max allowed inlet and gas ballast pressure |
0.5 bar gauge / 7 psig |
| Motor power 50/60Hz |
450 / 550W |
| Power connector 1-ph |
IEC EN60320 C13 |
| Nominal rotation speed 50/60Hz |
1500 / 1800rpm |
| Oil capacity min/max |
0.45 / 0.75 litres |
| Recommended oil |
Ultragrade 19 |
| Inlet flange |
NW25 |
| Exhaust flange |
NW25 |
| Noise level |
48 dB(A) @ 50 Hz |
| Operating temperature range |
12 – 40 °C |
| Weight (without oil) |
28 kg / 61.6 lb |
| Electrical Requirements |
100-120/200-230 VAC 50/60Hz, 1Ph |
