Absorbance: 200 to 999 nm

Fluorescence: 300 to 650 nm (Excitation) / 300 to 700 nm (Emission)

Luminescence: 300 to 700 nm

Absorbance: Monochromator, ± 1 nm

Fluorescence: Filter Based

Absorbance Specifications

Light Source

Xenon flash lamp

Detector

Photodiode

Wavelength Selection

Monochromator

Wavelength Range

200 to 999 nm, in 1 nm increments

Monochromator Bandwidth

2.4 nm

Monochromator Wavelength Accuracy

± 2 nm

Monochromator Wavelength Repeatability

± 0.2 nm

Dynamic Range

0 to 4.0 OD

Photometric Resolution

0.0001 OD

Pathlength Correction

Yes

Photometric Linearity

< 1% from 0 to 3.0 OD

Photometric Repeatability

< 0.5% at 2.0 OD

Fluorescence Intensity Specifications

Light Source

Tungsten halogen

Detector

PMT

Wavelength Selection

Filter-based

Wavelength Range

300 to 700 nm

Dynamic Range

> 6 decades

Sensitivity (Top and Bottom)

Fluorescein 5 pM (1 fmol/well, 96-well plate)

Luminescence Specifications

Dynamic Range

< 6 decades

Sensitivity

30 amol ATP (flash)

Detection System

Low noise PMT

Wavelength Range

300 to 700 nm

Alpha Detection Specifications

Light Source

Tungsten halogen

Sensitivity

300 amol of biotinylated LCK-P peptide

Read Speed

2 minutes (96-well plate)

General Specifications

Microplate Formats

6, 12, 24, 48, 96, 384 wells

Read Methods

End point, kinetic, spectral scanning, well-area scanning

Plate Shaking

Linear and orbital

Temperature Control

4-Zone incubation to 50°C, ± 0.2°C at 37°C

Dimensions (H x W x D)

12 x 15 x 15 in. (30.5 x 38.1 x 38.1 cm)

Weight

27 lb. (12.3 kg.)

Electrical Requirements

100-240V, 50/60Hz

Absorbance: 200 to 1000 nm

Fluorescence: 250 to 850 nm (Excitation) / 250 to 850 nm (Emission)

Luminescence: 250 to 850 nm

Absorbance: ≤ 4.0 nm

Fluorescence: 9.0 nm (Excitation) / 15 nm (Emission)

Absorbance: Monochromator, ± 1 nm

Fluorescence: Dual Monochromators, ± 1 nm

Absorbance: 200 to 1000 nm

Fluorescence: 250 to 850 nm (Excitation & Emission)

Luminescence: 250 to 850 nm

Absorbance: ≤ 4.0 nm

Fluorescence: 9.0 nm (Excitation) / 15 nm (Emission)

Absorbance: Monochromator, ± 1 nm

Fluorescence: Dual Monochromators, ± 1 nm

Absorbance: 200 to 1000 nm

Fluorescence: 250 to 850 nm (Excitation & Emission)

Luminescence: 250 to 850 nm

Absorbance: ≤ 4.0 nm

Fluorescence: 9.0 nm

Absorbance: Monochromator, ± 1 nm

Fluorescence: Dual Monochromators, ± 1 nm

Absorbance: 200 to 1000 nm

Fluorescence: 250 to 850 nm (Excitation) / 360 to 850 nm (Emission)

Luminescence: 250 to 850 nm

Absorbance: ≤ 4.0 nm

Fluorescence: 9.0 nm

Absorbance: Monochromator, ± 1 nm

Fluorescence: Dual Monochromators, ± 1 nm

Absorbance Specifications

Light Source

Xenon flash lamp

Wavelength Selection

Double monochromator

Wavelength Range

230 to 999 nm, in 1 nm increments

Bandpass

2 nm (230-285 nm), 4 nm (>285 nm)

Pathlength Correction

Yes

Monochromator Wavelength Accuracy

± 2 nm

Monochromator Wavelength Repeatability

± 0.2 nm

Dynamic Range

0 to 4.0 OD

Photometric Resolution

0.0001 OD

Photometric Accuracy

< 1% at 2.0 OD typical

Photometric Linearity

< 1% from 0 to 3.0 OD

Photometric Repeatability

< 0.5% at 2.0 OD

Reading Speed

96 wells: 11 seconds

384 wells: 22 seconds

Fluorescence Intensity Specifications

Light Source

Xenon flash lamp

Detector

Dedicated red shifted PMT

Wavelength Selection

Double grating monochromators (top read only)

Wavelength Range

250 to 900 nm

Dynamic Range

5 decades

Sensitivity (Top Read Only)

Fluorescein 2 pM typical (0.2 fmol/well, 384-well plate)

Luminescence Specifications

Dynamic Range

< 6 decades

Sensitivity

10 amol ATP typical (flash)

Detection System

Low noise PMT

Wavelength Range

300 to 700 nm
