System Pump Specifications
|
|
Flow Rate Range
|
0.001 to 25 ml/min (up to 50 ml/min during column packing)
|
|
Flow Rate Accuracy
|
± 1.2%
|
|
Flow Rate Precision
|
RSD <0.5%
|
|
Pressure Range
|
0 to 20 MPa (2900 psi)
|
|
Pressure Limits
|
Programmable upper and lower
|
|
Viscosity Range
|
0.35 to 10 cP (5 cP above 12.5 ml.min)
|
|
UV Monitor Specifications
|
|
Wavelength Range
|
190 to 700 nm in steps of 1 nm, up to 3 wavelengths
|
|
Absorbance Range
|
-6 to 6 AU
|
|
Resolution
|
0.001 mAU
|
|
Wavelength Reproducibility
|
± 0.01 nm
|
|
Linearity
|
Within ± 2% at 0 to 2 AU
|
|
Drift
|
≤ | 0.2 mAU | AU/h (2 mm cell at 280 nm)
|
|
Noise
|
< 0.08 mAU
|
|
Operating Pressure
|
0 to 2 MPa
|
|
Lamp Operating Time
|
> 5000 hours
|
|
Flow Cell
|
Optical path length: 2 mm
Cell volume: 2 ul
Total volume: 11 ul
|
|
Conductivity Monitor Specifications
|
|
Conductivity Range
|
0.01 to 999.9 mS/cm
|
|
Accuracy
|
± 0.01 mS/cm or ± 2%, whichever is greater (within 0.3 to 300 mS/cm)
|
|
Operating Pressure
|
0 to 5 MPa
|
|
Flow Cell Volume
|
22 ul
|
|
Temperature Monitor Range
|
0°C to 99°C
|
|
Temperature Monitor Accuracy
|
± 1.5°C within 4°C to 45°C
|
|
pH Monitor Specifications
|
|
pH Reading Range
|
0 to 14
|
|
Accuracy
|
± 0.1 pH unit within pH 2 to 12, temperature within ± 3°C from calibration temperature
|
|
Operating Pressure
|
0 to 0.5 MPa
|
|
Flow Cell Volume
|
76 ul
|
|
F9-C Fraction Collector Specifications
|
|
Number of Fractions
|
Up to 576
|
|
Vessel Types
|
Deep well plates, 96, 48, or 24 wells
|
|
Fraction Volumes
|
0.1 to 250 ml
|
|
Spillage-Free Mode
|
Automatic, Drop Sync, or Accumulator
|
|
Flammable Liquids
|
No
|
|
Delay Volume (UV-Dispenser Head)
|
205 ul, 86 ul with optional tubing kit (i.d. 0.25 mm)
|
|
Dimensions (W x D x H)
|
15.4 x 23 x 12.6 (39 x 58.5 x 32 cm)
|
|
Weight
|
46.3 lb. (21 kg)
|
