Agilent 1100 G1323B HPLC Gameboy Controller

Typically Ships Within Two Business Days!

Agilent 1100 G1323B HPLC Gameboy Controller

The Agilent 1100 G1323B Gameboy HPLC Controller is for use with HP/Agilent 1100 and 1200 HPLC systems. The Agilent hand-held control module self-configures all modules for total system control using controller-area network (CAN) communication and cabling. All instrument control parameters including column ID can be stored on credit-card sized PCMCIA (PC) cards for error-free transfer between instruments. A liquid-crystal display allows online monitoring of the signal during the run.

Our Price: $539.00

Wavelength Range	190 to 1100 nm
Wavelength Accuracy	< Â± 0.5 nm
Measurement Time	Typically 1.5 seconds (shortest time: 0.1 seconds)
Spectral Resolution	> 1.6
Dimensions (W x D x H)	13.5 x 22 x 7.3 in. (34.4 x 56 x 18.5 cm)
Weight	36.3 lb. (16.5 kg)
Electrical Requirements	100-120 or 220-240V, 50/60Hz

Maximum Flow Rate	10 ml/min per channel Reduced performance above 5 ml/min
Number of Channels	4
Internal Volume Per Channel	1ml per channel
Materials in Contact with Solvent	PTE, PEEK
pH Range	1 to 14

Type	Specification
Weight	0.8 kg
Dimensions (width x depth x height)	130 x 225 x 35 mm (5.1 x 8.9 x 1.4 inches)
Line voltage	22 VDC, Â± 10 %
Power consumption	6 W / 20.5 BTU/hour
Ambient operating temperature	0 to 55C (32 to 131F)
Ambient non-operating temperature	-40 to 70C (-40 to 158F)
Humidty	< 95%, at 25 â€š 40C (77 to 104F)
Operating Altitude	Up to 2000 m (6562 ft)
Non-operating altitude	Up to 4600 m (15092 ft)
Safety standards: IEC, CSA, UL, EN	Installation category II, pollution degree 2. For indoor use only. Research Use Only. Not for use in Diagnostic Procedures.

Maximum Flow Rate	0 to 5 ml/min per channel 5 to 10 ml/min at reduced degassing performance
Number of Channels	4
Internal Volume Per Channel	Typically 1ml per channel
Materials in Contact with Solvent	PTFE, FEP, PEEK
pH Range	1 to 14

Analysis Run Time	30 to 45 minutes
Number of Samples	Up to 12 samples/chips
Sample Volume	1 Âµl
Sizing Range	50 to 7000 bp
Electrical Requirements	100-240V, 50/60Hz

Temperature Range	4Â°C to 40Â°C
Temperature Accuracy at Ambient Temperatures (< 25 Â°C and humidity < 50%)	-1Â°C to +4Â°C at a setpoint of 4 Â°C
Temperature Accuracy at Ambient Temperatures (< 25Â°C and Humidity < 60%)	-1Â°C to +5Â°C at a setpoint of 4 Â°C
Weight	46 lbs. (20.7 kg)

Setable Flow Range	0.001 to 10 ml/min, in 0.001 ml/min increments
Flow Range	0.2 to 10.0 ml/min
Flow Precision	< 0.3% RSD (usually 0.15%), based on retention time, at 1 ml/min
Pressure	Operating range 0 to 40 MPa (0 to 400 bar, 0 to 5880 psi) up to 5 ml/min Operating range 0 to 20 MPa (0 to 200 bar, 0 to 2950 psi) up to 10 ml/min
Pressure Pulsation	< 2% amplitude (typically < 1%), at 1 ml/min isopropanol, at all pressures > 1 MPa (10 bar)
Recommended pH Range	1.0 to 12.5, solvents with pH > 2.3 should not contain acids which attack stainless steel
Gradient Formation	Low pressure quaternary mixing/gradient capability using proprietary high-speed proportioning valve Delay volume 800 to 1100 Âµl, dependent on back pressure
Composition Range	0 to 95% or 5 to 100%, user selectable
Composition Precision	< 0.2% SD, at 0.2 and 1 ml/min
Dimensions (H x W x D)	5.5 x 13.5 x 17 in
Electrical Requirements	100 to 120 or 22 to 240 VAC, 50/60 Hz, 220 VA

Detection Type	1024-element photodiode array
Light Source	Deuterium and tungsten lamps
Wavelength Range	190 - 640 nm
Short Term Noise (ASTM) Single and Multi-Wavelength	< Â± 3 x 10^-6 AU at 230 nm/4 nm
Drift	< 0.5 x 10^-3 AU/hr at 230 nm
Linear Absorbance Range	> 2 AU (5%) at 265 nm
Wavelength Accuracy	Â± 1 nm
Wavelength Bunching	2 - 400 nm
Slit Width	Fixed 4 nm slit
Diode Width	~ 0.5 nm

Setable Flow Range	Setpoints 0.001 to 5 ml/min, in 0.001 ml/min increments
Flow Range	0.1 to 5 ml/min
Flow Precision	< 0.07% RSD or < 0.02 min SD
Flow Accuracy	Â± 1% or 10 ul/min
Pressure	Operating range 0 to 400 bar (0 to 5880 psi) up to 5 ml/min
Pressure Pulsation	< 2% amplitude (typically < 1%) at 1 ml/min isopropanol, at all pressures > 1 MPa
Compressibility Compensation	User-selectable, based on mobile phase compressibility
Hydraulic System	Two dual pistons in series pumps with proprietary servo-controlled variable stroke drive, floating piston design and active inlet valve
Recommended pH Range	1.0 to 12.5; solvents with pH < 2.3 should not contain acides with attack stainless steel
Gradient Formation	High-pressure binary mixing, delay volume 180 to 480 ul without mixer, 600 to 900 ul with mixer, dependent upon back pressure
Composition Range	1 to 99% or 5 ul/min per channel
Composition Precision	< 0.5% absolute
Composition Accuracy	< 0.15% RSD at 1 ml/min

Time to Move Between Adjacent Cell Positions	< 1 second
Position Repeatability	Â± 0.1 mm
Step Resolution	0.060 mm
Temperature Range for Thermostatting (Cell Holder Only)	5 to 90Â°C
Temperature Difference Between any Two Cell Positions	0.3Â°C (with a water bath at 37Â°C)

Component	Model
Quaternary or Binary Pump	G1311A or G1312A
Thermal Autosampler	G1329A
Thermal Unit	G1330B
DAD Detector	G1315C
TCC (Column Compartment)	G1316A
Degasser	G1379B
Optional RID Detector	G1362A
Optional Fraction Collector	G1364C
Computer & Software	Windows 11 Professional 64-Bit w/ ChemStation Version 4.3 Software Installed

Mass Range	10 to 3,000 m/z
Mass Accuracy	Â± 0.13 Da
Scan Speed	10,400 Da/sec
SIM Sensitivity, ESI Positive	Signal-to-noise ratio > 250:1 (1 pg of reserpine injected on column, quantifying the m/z 609 ion)
Included Ionization Source	G1948B ESI
Dimensions (W x H x D)	14 x 18 x 25 in. (35 x 45 x 63.5 cm)
Weight	137.6 lb. (63.4 kg)
Electrical Requirements	200-230VAC, 60Hz or 200-240VAC, 50Hz

Detection Type	Refractive Index
Refractive Index Range	1.00 to 1.75 RIU, calibrated
Measurement Range	Â± 600 x 10^-6 RIU
Short Term Noise	< Â± 2.5 x 10^-9 RIU
Drift	< 200 x 10^-9 RIU/h
Valves	Automatic purge and automatic solvent recycle

Detection Type	Multi-signal fluorescence detector with rapid on-line scanning capabilities and spectral data analysis
Performance Specifications	Single Wavelength Operation: RAMAN (H2O) > 500 (noise reference measured at signal), Ex=350 nm, Em=397 nm, dark value 450 nm, standard flow cell RAMAN (H2O) > 3000 (noise reference measured at dark value), Ex=350 nm, Em=397 nm, dark value 450 nm, standard flow cell Dual Wavelength Operation: RAMAN (H2O) > 300 Ex 350 nm, Em 397 nm and Ex 350 nm, Em 450 nm, standard flow cell
Excitation Monochromator	Range: settable 200 nm - 1200 nm and zero-order Bandwidth: 20 nm (fixed) Monochromator: concave holographic grating, F/1.6, blaze: 300 nm
Emission Monochromator	Range: settable 200 nm - 1200 nm and zero-order Bandwidth: 20 nm (fixed) Monochromator: concave holographic grating, F/1.6, blaze: 400 nm
Wavelength characteristic	Repeatability: +/- 0.2 nm Accuracy: +/- 3 nm setting

Hydraulic System	Two dual-piston in-series pumps with proprietary servo-controlled variable stroke design, power transmission by ball screws, and smooth motion control of pistons for active damping
Settable Flow Range	0.001 to 5.0 mL/min, in 0.001 mL/min increments
Flow Precision	â‰¤ 0.07 % RSD or 0.005 min SD, whatever is greater (0.2 to 5.0 mL/min)
Flow Accuracy	Â± 1 % or 10 uL/min, whichever is greater. Pumping degassed H2O at 10 MPa (100 bar)
Pressure Operating Range	Up to 120 MPa (1200 bar) at up to 2 mL/min; 80 MPa (800 bar) at 5 mL/min
Pressure Pulsation	<1 % amplitude or < 0.5 MPa (5 bar), whichever is greater
Gradient Formation	High-pressure binary mixing
Delay Volume	Jet Weaver V35: < 45 uL; Jet Weaver V100: <75 uL. For lowest delay volumes, the Jet Weaver can be removed
Settable Composition Range	Settable range: 0 to 100 %; Recommended Range 1 â€“ 99 % or 5 ul/min per channel, whichever is greater
Composition Precision	< 0.15 % RSD or 0.01 min SD, whatever is greater
Integrated Degassing Unit	Number of channels: 2; Internal volume per channel: 1.5 mL

Settable Flow Range	0.001 to 5 ml/min, in 0.001 ml/min increments
Flow Precision	≤ 0.07 % RSD or 0.01 min SD, whichever is greater
Flow Accuracy	± 1 % or ± 10 uL/min, whichever is greater
Pressure Operating Range	Up to 80 MPa (800 bar, 11603 psi) up to 5 mL/min
Pressure Pulsation	< 1 % amplitude or < 0.5 MPa (5 bar), whichever is greater
Recommended pH Range	1.0 to 12.5, solvents with pH < 2.3 should not contain acids which attack stainless steel
Gradient Formation	Low pressure quaternary mixing/gradient capability using proprietary high-speed proportioning valve
Delay Volume	≤ 350 µL (default configuration)
Composition Range	Settable range: 0 to 100 % Recommended range: 1 to 99 %
Composition Precision	< 0.15 % RSD or 0.02 min SD, whichever is greater
Integrated Degassing Unit	Number of channels: 4 Internal volume per channel: 1.5 ml

Maximum Flow Rate	10 ml/min per channel
Number of Channels	4
Internal Volume per Channel	Typically 12 mL per channel
Materials in Contact with Solvent	PTFE, PEEK
pH Range	1 to 14

Pressure	0 – 60 MPa (0 – 600 bar, 0 – 8702 psi)
GLP Features	Early maintenance feedback (EMF) for continuous tracking of instrument usage with user-settable limits and feedback messages. Electronic records of maintenance and errors
Communications	Controller Area Network (CAN), Local Area Network (LAN) ERI: ready, start, stop and shut-down signals
Safety Features	Leak detection, safe leak handling, leak output signal for shutdown of pumping system, and low voltages in major maintenance areas
Injection Range	0.1 – 100 uL in 0.1 uL increments with 100 uL up to 60 MPa
Precision	< 0.25 % RSD of peak areas from 5 uL to 100 uL
Carryover	Typically < 0.004% with needle wash
Sample Viscosity Range	0.2 to 5 cP
Sample Capacity	132 x 2 ml vials 100 x 2 mL vials 36 x 6 mL vials
Injection Cycle Time	Typically 18 s for draw speed 200 uL/min and injections volume of 1 uL

Pressure	Up to 600 bar (8700 psi)
GLP Features	Early maintenance feedback (EMF), electronic records of maintenance and errors
Communications	Controller-area network (CAN). RS232C, APG-remote standard, optional four external contact closures and BCD vial number output
Safety Features	Leak detection and safe leak handling, low voltages in maintenance areas, error detection and display
Injection Range	0.1 to 100 ul in 0.1 ul increments
Precision	Typically < 0.25% RSD of peak areas from 5 to 100 ul Typically < 1% RSD of peak areas from 1 to 5 ul
Carryover	Typically < 0.01 % using the following conditions: Column: 125 x 4 mm Hypersil ODS, 5 µm Mobile phase: Water/Acetonitrile = 80/20 Flow rate: 1 ml/min Injection volume: 1 ul caffeine (1 mg/ml), 5 ul water to test carryover Outside wash of needle before injection: 20 sec with water using flush port
Sample Viscosity Range	0.2 to 50 cp
Sample Capacity	2 × well plates (MTP) + 10 × 2 ml vials 108 x 2-mL vials in 2 x 54 vial plate plus 10 additional 2 mL vials 30 x 6-mL vials in 2 x 15 vial plate plus 10 additional 2 mL vials 54 Eppendorf tubes (0.5/1.5/2.0mL) in 2 x 27 Eppendorf tube plate
Injection Cycle Time	Typically < 30 s using following standard conditions: Default draw speed: 200 ul/min Default eject speed: 200 ul/min Injection volume: 5 ul

Detection Type	Double-beam photometer
Light Source	Deuterium lamp
Wavelength Range	190 - 600 nm
Noise	< Â± 0.25 x 10-5 AU, at 230 nm
Drift	1 x 10-4 AU/hr, at 230 nm
Linearity	>2.5 AU upper limit
Wavelength Accuracy	Â± 1 nm, self-calibration with deuterium lines, verification with holmium oxide filter
Wavelength Precision	< Â± 0.1 nm
Slit Width	6.5nm typical over whole wavelength range

Temperature Range	10Â°C below ambient to 80Â°C
Temperature Stability	Â± 0.15Â°C
Temperature Accuracy	Â± 0.8Â°C
Column Capacity	Three 30 cm columns
Warm-Up / Cool-Down Time	5 minutes from ambient to 40Â°C 10 minutes from 40Â°C to 20Â°C

Hydraulic System	Two dual piston in series pumps with servo-controlled variable stroke drive, power transmission by gears and ball screws, floating pistons
Setable Flow Range	0.001 to 5 mL/min, in 0.001 mL/min increments
Flow Range	0.05 to 5.0 mL/min
Flow Precision	< 0.07% RSD or < 0.02 min SD, whatever is greater
Flow Accuracy	Â± 1% or 10 Âµl/min, what ever is greater
Pressure Operating Range	0 to 60 MPa (0 to 600 bar, 0 to 8,700 psi) up to 5 mL/min
Pressure Pulsation	< 2% amplitude or < 3 bar at 1 mL/min isopropanol, at all pressures > 1 MPa (10 bar, 147 psi)
Compressibility Compensation	Pre-defined, based on mobile phase compressibility
Recommended pH Range	1.0 to 12.5, solvents with pH < 2.3 should not contain acids which attack stainless steel
Gradient Formation	High-pressure binary mixing
Delay Volume	Â± 1% or 10 Âµl/min, what ever is greater Low delay volume configuration: 120 Âµl

Mass Range	25 to 20,000 m/z
Mass Accuracy	< 1 ppm (measured at m/z 609.2807)
Scan Speed	30 spectra/second (from 100 to 3,200 m/z)
MS Sensitivity with AJS	Signal-to-noise ratio > 50:1, Noise = 1 Ã— RMS (1 pg reserpine injected on-column, measured at m/z 609.2807)
Included Ionization Source	G1958B Jet Stream Electrospray
Dimensions (L x W x H)	32.7 x 28.7 x 52.4 in. (83 x 73 x 133 cm)
Weight	260 lb. (117.9 kg)
Electrical Requirements	200-220VAC, 50/60Hz, 15A

Mass Range	10 to 1,350 m/z
Mass Accuracy	Â± 0.13 u within the calibrated mass range in scan mode
Scan Speed	10,000 u/s in fast mode and 2,500 u/s in normal mode
SIM Sensitivity	ESI at 400 Î¼/min or APCI at 1000 Î¼/min Selected ion monitoring of m/z 609.3 Positive ionization 1 pg reserpine, 100:1 RMS (20:1 peak-to-peak)
Included Ionization Source	G1948B ESI
Dimensions (H x W x D)	26 x 15 x 29 in. (65 x 39 x 75 cm)
Weight	110 lb. (50 kg)
Electrical Requirements	200-240V, 50/60Hz

Find by Price

Find by Agilent HPLC Component Series

Find by Agilent HPLC System Series

Find by AKTA FPLC System Series

Find by Application Capabilities

Find by Aspiration Rate

Find by Aspiration Speed

Find by Autoclave Chamber Volume

Find by Balance Capacity

Find by Balance Readability

Find by Balance Type

Find by Block Configuration

Find by Blowdown Evaporator Capacity

Find by Brand

Find by Cell Size Range

Find by Cell Washing Capability

Find by Centrifugal Evaporator Compatibility

Find by Centrifugal Evaporator Maximum Speed

Find by Centrifugal Evaporator Refrigeration

Find by Centrifuge Adapter Rotor Compatibility

Find by Centrifuge Compatibility

Find by Centrifuge RCF

Find by Centrifuge Refrigeration

Find by Centrifuge Rotor Compatibility

Find by Centrifuge Type

Find by Chiller Cooling Capacity

Find by Chiller Flow Rate

Find by Chiller Lowest Temperature

Find by Cold Trap Temperature

Find by Concentration Range

Find by Detectors Included

Find by Dry Bath Heater Capacity

Find by Dry Bath Heater with Cooling

Find by FPLC Component Type

Find by FPLC System Flow Rate Range

Find by FPLC System Pressure Range

Find by Freeze Dryer Accessory Type

Find by Freeze Dryer Material

Find by Freeze Dryer Size

Find by Freeze Dryer Temperature

Find by Freeze Dryer Voltage

Find by Freezer Capacity

Find by Freezer Low Temperature

Find by Freezer Style

Find by Gradient Function

Find by Head Type

Find by Histology Centrifuge Maximum Speed

Find by Hotplate Stirrer Maximum Temperature

Find by Hotplate Stirrer Speed Range

Find by Hotplate Stirrer Type

Find by HPLC Component Type

Find by Includes Stoppering or Bulk Tray Dryer

Find by Incubator Capacity

Find by Incubator Refrigeration

Find by Incubator Shaker Refrigeration

Find by Incubator Type

Find by Integrated Vacuum Pump

Find by Liquid Sterilization?

Find by Mass Range

Find by Maximum Current

Find by Maximum Dry Bath Heater Temperature

Find by Maximum Flask Size

Find by Maximum Heating Bath Flask Size

Find by Maximum Heating Bath Temperature

Find by Maximum Incubator Shaker Speed

Find by Maximum Incubator Shaker Temperature

Find by Maximum Incubator Temperature

Find by Maximum Mixer Speed

Find by Maximum Oven Temperature

Find by Maximum Pumping Speed

Find by Maximum Rotary Evaporator Temperature

Find by Maximum RT-PCR Ramp Rate

Find by Maximum Voltage

Find by Maximum Vortexer Speed

Find by Maximum Water Bath Temperature

Find by Maximum Watts

Find by Microplate Reader Capability

Find by Microplate Types

Find by Mixer Type

Find by Multiple Buffer Capability

Mass Range	2 to 2,000 m/z
Mass Accuracy	Â± 0.13 Da
Scan Speed	10,400 Da/sec
SIM Sensitivity, ESI Positive	Signal-to-noise ratio > 75:1 (1 pg of reserpine injected on column, quantifying the m/z 609 ion)
Included Ionization Source	G1948B ESI
Dimensions (W x H x D)	14 x 18 x 25 in. (35 x 45 x 63.5 cm)
Weight	137.6 lb. (63.4 kg)
Electrical Requirements	200-230VAC, 60Hz or 200-240VAC, 50Hz

GLP Features	Early maintainece feedback (EMF), electronic records of maintainence and errors
Communications	Controller-area network (CAN). RS232C, APG remote standard, optional four external contact closures and BCD vial number output
Safety Features	Leak detection and safe leak handling, low voltages in maintence areas, error detection and display
Injection Range	0.1 to 100 Âµl in 0.1 Âµl increments Up to 1500 Âµl with multiple draw (hardware modification required)
Precision	Typically < 0.25 % RSD from 5 â€š 100 Âµl, Typically < 1 % RSD from 1 - 5 Âµl
Pressure Range	400 bar (5800 psi)
Sample Viscosity Range	0.2 to 5 cp
Sample Capacity	2 Ã— well-plates (MTP) + 10 Ã— 2 ml vials 108 x 2 ml vials in 2 x 54 vial plate plus 10 additional 2 mL vials 30 x 6-mL vials in 2 x 15 vial plate plus 10 additional 2 mL vials 54 Eppendorf tubes (0.5/1.5/2.0mL) in 2 x 27 Eppendorf tube plate
Injection Cycle Time	Typically < 30 s using following standard conditions: Default draw speed: 200 Âµl/min Default eject speed: 200 Âµl/min Injection volume: 5 Âµl
Carry-Over	Typically < 0.01 % using the following conditions: Column: 125 x 4 mm Hypersil ODS, 5 Âµm Mobile phase: Water/Acetonitrile = 80/20 Flow rate: 1 ml/min Injection volume: 1 Âµl caffeine (1 mg/ml), 5 Âµl water to test carryover Outside wash of needle before injection: 20 sec with water using flush port

Hydraulic system	Two dual piston in series pumps with proprietary servo-controlled variable stroke drive, floating piston design and active inlet valve
Setable flow range	0.001 to 10 mL/min, in 0.001 mL/min increments
Flow range	0.05 to 10.0 mL/min
Flow precision	< 0.07% RSD or < 0.02 min SD, whatever is greater based on retention time at constant ambient temperature
Flow accuracy	Â± 1% or 10 Âµl/min whatever is greater
Pressure	Operating range 0 400 bar (0 to 5880 psi) up to 5 ml/min
Pressure pulsation	< 2 % amplitude (typically < 1 %), at 1 ml/min isopropanol, at all pressures > 1 MPa
Compressibility compensation	User-selectable, based on mobile phase compressibility
Recommended pH range	1.0 to 12.5, solvents with pH < 2.3 should not contain acids which attack stainless steel
Gradient formation	High-pressure binary mixing, delay volume 180 â€š 480 Âµl without mixer, 600 to 900 Âµl with mixer, dependent on back pressure
Composition range	1 to 99 % or 5 Âµl/min per channel, whatever is greater
Composition precision	< 0.5% absolute
Composition accuracy	Â± 0.15% RSD, at 1 ml/min

Component	Model
Binary Pump	G4220A
Thermal Autosampler	G4226A
Thermal Unit	G1330B
DAD Detector	G4212A
TCC (Column Compartment)	G1316C
Degasser	Integrated in G4220A
Computer & Software	Windows 11 Professional 64-Bit w/ ChemStation Version 4.3 Software Installed

Temperature Range	10Â°C below ambient to 100Â°C
Temperature Stability	Â± 0.05Â°C
Temperature Accuracy	Â± 0.8Â°C
Column Capacity	Three 30 cm columns
Warm-Up / Cool-Down Time	5 minutes from ambient to 40Â°C 10 minutes from 40Â°C to 20Â°C

Settable Flow Range	Set points 0.001 to 10 ml/min, in 0.001 ml/min increments
Flow Range	0.2 to 10.0 ml/min
Flow Precision	â‰¤ 0.07% RSD, or â‰¤ 0.02 min SD whatever is greater, based on retention time at constant room temperature
Flow Accuracy	Â± 1% or 10 Âµl/min, whatever is greater, pumping degassed H₂O at 10 MPa (100 bar)
Pressure Operating Range	Operating range up to 60 MPa (600 bar, 8700 psi) up to 5 ml/min Operating range up to 20 MPa (200 bar, 2950 psi) up to 10 ml/min
Pressure Pulsation	< 2% amplitude (typically < 1.0%) or < 0.3 MPa (3 bar, 44 psi), whatever is greater, at 1 ml/min isopropanol, at all pressures > 1 MPa (10 bar, 145 psi)
Recommended pH Range	1.0 to 12.5, solvents with pH < 2.3 should not contain acids which attack stainless steel
Gradient Formation	Low pressure quaternary mixing/gradient capability using proprietary high-speed proportioning valve
Delay Volume	600 to 900 Âµl, dependent on back pressure; measured with water at 1 ml/min
Composition Range	0 to 100% in 0.1% increments
Composition Precision	< 0.2% RSD or < 0.04 min SD, whatever is greater, at 1 ml/min; based on retention time at constant room temperature
Integrated Degasser	Number of channels: 4 Internal volume per channel: 1.5 ml
Dimensions (H x W x D)	7.1 x 15.6 x 17.2 in. (18 x 39.6 x 43.6 cm)
Electrical Requirements	100 to 240 V, 50/60 Hz, 80 VA

Maximum Flow Rate	0 to 5 ml/min per channel
Number of Channels	4
Internal Volume Per Channel	Typically 1ml per channel
Materials in Contact with Solvent	PTFE, FEP, PEEK
pH Range	1 to 14

Injection Range	Default: 0.1 to 100 ÂµL in 0.1 ÂµL increments; optional: 20 ÂµL or 40 ÂµL (using 100 ÂµL analytical head)
Injection Precision	<0.2 % RSD or SD <10 nL, whatever is greater
Injection Linearity	0.9999 in the range of 0.1 to 100 ÂµL
Pressure Range	Up to 800 bar
Sample Viscosity Range	0.2 to 5.0 cP
Sample Capacity	1H Drawer: up to 8 drawers and 16 positions; Shallow well plates (MTP) 2H Drawer: up to 4 drawers and 8 positions; MTP, deep well plates, vials, Eppendorf 3H Drawer: up to 2 drawers and 4 positions; MTP, deep well plates, vials up to 6 mL, Eppendorf
Injection Cycle Time	<10 s using following standard conditions: Default draw speed: 100 ÂµL/min Default eject speed: 400 ÂµL/min Injection volume: 1 ÂµL
Carryover	<0.003 % (30 ppm) Multisampler Standard and Dual Needle <0.0009 % (9 ppm) Multisampler Multiwash
Multiwash	Outer needle wash and seat backflush for carryover reduction with up to 3 different solvents
Dimensions (H x W x D)	12.6 x 15.6 x 18.4 in. (32 x 39.6 x 46.8 cm)
Weight	48.5 lb. (22 kg.)
Electrical Requirements	100 to 240V, 50/60Hz, 180VA
