Thermo Scientific Precision CIR 35 Circulating Water Bath
The Thermo Scientific Precision CIR 35 Circulating Water Bath is a high performance general purpose 35L bath intended for a wide range of applications. The CIR 35 is the ideal option when temperature uniformity and control are particularly important, such as when working with enzymes and in serological applications.
All of our equipment is in excellent condition and will be fully tested to perform at factory specifications before being shipped.
INCLUDED:
The Thermo Scientific Precision CIR 35 Circulating Water Bath includes:
The Thermo Scientific Precision CIR 35 Circulating Water Bath includes:
- > Gable Cover
- > Power Cord
- > Operator's Manual
- > Full 180 Day Parts and Labor Warranty
Thermo Scientific Precision CIR 35 Circulating Water Bath Specifications
|
Temperature Range |
Ambient +5C to 100C |
|
Temperature Uniformity |
0.05C at 37C |
|
Control |
Digital |
|
Capacity |
35L (9.2 gal) |
|
Bath Dimensions (L x W x H) |
19 x 36 x 9.5 in (48.3 x 91.4 x 24.1
cm)
|
|
Electrical Requirements |
100-115V, 50/60Hz, 12A
200-230V, 50/60Hz, 6A |
| Heating Capacity | 1500W |
| Temperature Stability | 0.1C |
| Temperature Presets | 4 |
| Overall Dimensions (L x W x H) | 21.5 x 45.7 x 11.8 in (54.6 x 116 x 30 cm) |
Water Bath Inspection and Recertification Checklist
- Confirm Power Supply and Pcb Are Outputting Correct Voltages
- Inspect Display and Replace Any Dim/Dead Pixels
- Confirm All Buttons, Knobs, And Switches Are Functioning Properly
- Inspect Water Reservoir for Holes, Rust and Other Damage
- Fill With Water and Confirm Unit Has No Leaks
- Inspect Lid for Any Damage and Replace Hinges and Handle as Needed
- Inspect For Any Internal Leaks Coming from The Water Reservoir
- Inspect Internal Wiring for Any Breakages or Tears. Replace All Underperforming Components.
- Inspect Internal Insulation for Burns or Breaks, And Replace as Needed
- Check Feet and Confirm Bath Is Sitting Balanced
- Calibrate Temperature Accuracy and Temperature Uniformity with Nist Traceable Temperature Probe
- Ensure Cosmetics Are Acceptable
Thermo Precision CIR 35 Manual
