GLP Features

Early maintainece feedback (EMF), electronic records of maintainence and errors

Communications

Controller-area network (CAN). RS232C, APG remote standard, optional four external contact closures and BCD vial number output

Safety Features

Leak detection and safe leak handling, low voltages in maintence areas, error detection and display

Injection Range

0.1 – 100 µl in 0.1 µl increments Up to 1500 µl with multiple draw (hardware modification required)

Precision

Typically < 0.5 % RSD of peak areas from 5 – 100 µl, Typically < 1 % RSD from 1 – 5 µl

Sample Viscosity Range

0.2 – 5 cp

Sample Capacity

2 × well-plates (MTP) + 10 × 2 ml vials [Not Included]

100 x 2 ml in one tray 40 x 2 ml in half tray [Included]

Injection Cycle Time

Typically < 30 s using following standard conditions: Default draw speed: 200 µl/min Default eject speed: 200 µl/min Injection volume: 5 µl

Carry-Over

Typically < 0.01 % using the following conditions: Column: 125 x 4 mm Hypersil ODS, 5 µm Mobile phase: Water/Acetonitrile = 80/20 Flow rate: 1 ml/min Injection volume: 1 µl caffeine (1 mg/ml), 5 µl water to test carryover Outside wash of needle before injection: 20 sec with water using flush port
