New Brunswick I24R Refrigerated Incubator Shaker

The New Brunswick I24R Refrigerated Incubator Shaker is an easy-to-use benchtop orbital incubator shaker that combines a triple-eccentric counterbalanced shaking mechanism with precision temperature control including refrigeration for uniform motion and years of quiet, dependable operation. This cast iron triple-eccentric counterbalanced drive is specifically designed to support high-speed applications and heavy workloads. A wide speed range of 25 to 500 RPM is utilized with a temperature range of Ambient -15°C to 60°C, which is supported by a powerful fan and temperature control to provide rapid heat up and temperature recovery after door opening. Audible and visual alarms alert the user to setpoint deviations or end of study. Also featured on the I24 Incubator Shaker is a RS-232 interface for data logging directly to a PC. This M1344-0014 model of the I24R Refrigerated Incubator Shaker also features an orbit size of 2.5 cm (1 in.). A large clear lid enables easy viewing of the user's culture media. Microprocessor controls with digital display enable easy operation and accurate setpoint regulation of temperature, speed and running time.

All of our equipment is fully tested to perform at factory specifications before being shipped.

New Brunswick I24R Refrigerated Incubator Shaker Specifications

Speed Range	25 to 500 RPM
Speed Control Accuracy	± 1 RPM
Temperature Range	Ambient -15°C to 60°C (minimum 4°C)
Temperature Uniformity	± 0.1°C at 37°C
Timer	0.1 to 99.9 hours, or continuous
Program Modes	Constant speed and temperature and timed shaking
Orbit Size	2.5 cm (1 in.)
Platform Size	18 x 18 in. (46 x 46 cm)
Chamber Dimensions (W x D x H)	20.4 x 21 x 13.6 in. (51.7 x 53.3 x 34.4 cm)
Overall Dimensions (W x D x H)	22 x 30 x 24.1 in. (55.8 x 76.2 x 61.1 cm)
Weight	184 lb. (83.6 kg)
Electrical Requirements	120V, 60Hz, 1Ph, 1500VA
