Detection type
|
Multi-signal fluorescence detector with rapid on-line
scanning capabilities and spectral data analysis
|
|
Performance Specifications
|
10 fg Anthracene, Ex=250 nm, Em=400 nm*
RAMAN (H2O) > 200 (FLF rev A)
RAMAN (H2O) > 400 (FLF rev >A)
Ex=350 nm, Em=397 nm, dark value 450 nm, standard flow cell time constant=4 seconds (8 seconds response time)
|
|
Light source
|
Xenon Flash Lamp, normal mode 20 W,
economy mode 5 W
|
|
Pulse frequency
|
296 Hz for single signal mode, 74 Hz for spectral mode
|
|
Excitation monochromator
|
Range: 200 nm - 700 nm and zero-order
Bandwidth: 20 nm (fixed)
Monochromator:concave holographic grating, F/1.6, blaze: 300
nm
|
|
Emission monochromator
|
Range: 280 nm - 900 nm and zero-order
Bandwidth: 20 nm (fixed)
Monochromator:concave holographic grating, F/1.6, blaze: 400
nm
|
|
Reference System
|
in-line excitation measurement
|
|
Timetable programming
|
up to 4 signal wavelengths, response time, PMT Gain,
baseline behavior (append, free, zero), spectral parameters
|
|
Spectrum acquisition
|
Excitation or Emission spectra
Scan speed: 28 ms per datapoint (e.g. 0.6 s/spectrum 200-400 nm, 10 nm step)
Step size: 1-20 nm
Spectra storage: All
|
|
Wavelength characteristic
|
Repeatability ±0.2 nm
Accuracy ±3 nm setting
|
|
Flow cells
|
Standard: 8 µl volume and 20 bar (2 MPa) pressure maximum,
quartz
Optional: Fluorescence cuvette for offline spectroscopic measurements with 1 ml syringe, 8 µl volume, quartz
|
|
Control and data evaluation
|
Agilent ChemStation for LC, Agilent 1100 Control Module with
limited spectral data analysis and printing of spectra
|
|
Analog outputs
|
Recorder/integrator: 100 mV or 1 V, output range >102
luminescence units, two outputs
|
|
Communications
|
Controller-area network (CAN),
GPIB, RS-232C, LAN, APG
Remote: ready, start, stop and shut-down signals
|
|
Safety and Maintenance
|
Extensive diagnostics, error detection and display (through control module and ChemStation), leak detection, safe leak handling, leak output signal for shutdown of pumping system. Low voltages in major maintenance areas.
|
|
GLP Features
|
Early Maintenance Feedback (EMF) for continuous tracking of
instrument usage in terms of lamp burn time with user-settable limits and feedback messages. Electronic records of maintenance and errors. Verification of wavelength accuracy, using the Raman band of water
|
|
Housing
|
All materials recyclable
|
Environment
|
0 to 40 °C constant temperature at <95% humidity
(non-condensing)
|
|
Dimensions and Weight
|
140 mm x 345 mm x 435 mm (5.5 x 13.5 x 17 inches)
(height x width x depth)
25.5 lbs
|
